FLUXUS G601

Measurement uncertainty at the measuring point (volumetric flow rate)

±1 ~ 2 % of reading ±0.005 m/s

Measurement uncertainty of the measuring system (volumetric flow rate)

±0,3 % of reading ±0.005 m/s

Repeatability

0.15 % of reading ±0.005 m/s

Flow velocity range

0.01 ~ 35 m/s, depending on pipe diameter

Ex zone transmitter

only safe area

Power supply

Li-ION 7.2V/6.2Ah Operat. time >25h

Available transducers

Shear wave/Lamb wave

for pipe sizes range

7mm ~ 1600mm

for temperature range

-40°C ~ +200°C

Outputs

4-20mA active/passive
pulse/frequency/binary

Inputs

Pt100/Pt1000
4-20mA passive

Digital communication

Modbus RTU

Additional Information

For more detailed Information please download the Technical Specifications
