FLUXUS G721CA

Non-invasive compressed air flow metering with the FLUXUS G721 CA

Compressed Air는 효율성 문제로 매우 비싼 에너지 형태입니다. 공압 도구로 수행되는 모든 기계적 작업에는 약 20배의 전기 에너지가 소비되어야 합니다. 그러나 이러한 열악한 수율에도 불구하고 압축 공기는 생산 관련 이점 때문에 많은 산업에서 실질적으로 필수 불가결한 요소입니다. 따라서 귀중한 매체를 가능한 한 효율적으로 사용하는 것이 더욱 중요합니다. 이러한 효율성 문제를 줄이기 위한 최적의 유량계가 G721CA입니다.


FLUXUS G721CA

Measurement uncertainty of the measuring system (volumetric flow rate)

±0,3 % of reading ±0.005 m/s

Measurement uncertainty at the measuring point (volumetric flow rate)

±1 ~ 2 % of reading ±0.005 m/s

Repeatability

0.15 % of reading ±0.005 m/s

Flow velocity range

0.01 ~ 35 m/s, depending on pipe diameter

Ex zone transmitter

ATEX/IECEx Zone 2, FM Class I /Div 2

Power supply

100-230VAC, 24DC, 12DC

Available transducer

Shear wave/Lamb wave

for Ex zones

ATEX/IECEx Zone 1/Zone 2
FM Class I - Div2

for pipe sizes range

15mm ~ 250mm

for temperature range

-40°C ~ +170°C

Outputs

4-20mA active/passive
4-20mA HART active/passive
pulse/frequency/binary

Inputs

Pt100/Pt1000
4-20mA active/passive

Digital communication

Modbus RTU/TCP
BACnet MSTP/IP
M-Bus
Profibus PA
Foundation Fieldbus

Advanced Meter Verification

available

Additional Information

For more detailed Information please download the Technical Specifications



어플리케이션

 반도체

 제약, 식품 및 음료

 제조 산업



FLUXUS G721CA ( Compressed Air Flowmeter )

l​ 외부 배관 벽에서 안정적이고 유지보수가 필요 없는 압축 공기 유량 측정 가능

   (강관의 경우 >3bar, 플라스틱 배관의 경우 대기압 이하)

l​ 한 쌍의 온도 보상 및 추적 가능한 트랜스듀서로 인해 측정이 매우 정확함
l​ 최저에서 최고 유속까지 매우 높은 측정 역학
l​ 공정 중단 및 배관 작업이 불필요
l​ 누출 위험 없음압력 손실 없음

l​ 양방향 유량 측정 가능
